Load Frames

Product Description

Load Frames

• Load Frame, Motorised, 30 speeds (50 kN) cap.Two Pillar type, Detachable frame, Enclosed motor and gear system, Jewel lamps indicating direction of motion, Speed chart.
• Consists of a cabinet which housed the gear system & motor with sturdy angle iron frame.
• The loading is done through the bottom loading platen, which is carried on a lead screw which advances upwards.
• The top load bracket which slides over two upright pillars, can be positioned at any desired height and locked. It caries a screw adaptor for standard Proving ring. Rate of strains : 30, ( 6 mm/min to 0.00048 mm/min by interchanging the drive and driven gears, another set of 24 rates of strain can be obtained. 220V, 1 Ph, 50 cycles, AC supply.
• The Loading part of the unit is detachable from the main unit for ease of transport and to avoid damage to the tension rods.
